Description
FD3200L - Eaton Cutler-Hammer - Feed Thru 200 Amp 3 Pole 600 Volt Molded Case Circuit Breaker
Eaton Series C complete molded case circuit breaker, Series C, F-frame molded case circuit breaker, 200 A, Three-pole, Line and load terminals, Thermal magnetic trip, FD breaker
GENERAL SPECIFICATIONS
| Product Name | Eaton Series C complete molded case circuit breaker |
| Catalog Number | FD3200L |
| UPC | 786679015407 |
| Product Length/Depth | 3.38 in |
| Product Height | 6 in |
| Product Width | 4.13 in |
| Product Weight | 4.5 lb |
| Certifications | UL Listed |
PRODUCT SPECIFICATIONS
| Amperage Rating | 200 A |
| Voltage rating | 600 Vac, 250 Vdc |
| Trip Type | T186 |
| Circuit breaker type | FD |
| Circuit breaker frame type | Complete breaker |
| Series | Series C |
| Terminals | Line and load |
| Frame | F |
| Frequency rating | 50 to 60 Hz |
| Interrupt rating | 65 kAIC at 240 Vac 35 kAIC at 480 Vac |
| Number of poles | Three-pole |
PRODUCT DATASHEET
