Description
FDC3150L - Eaton Cutler-Hammer - Feed Thru 150 Amp 3 Pole 600 Volt Molded Case Circuit Breaker
Eaton Series C complete molded case circuit breaker, F-frame, FDC, Complete breaker, Fixed thermal, fixed magnetic trip type, Three-pole, 150A, 600 Vac, 250 Vdc, 200 kAIC at 240 Vac, 100 kAIC at 480 Vac, Line and load, 50/60 Hz
GENERAL SPECIFICATIONS
| Product Name | Eaton Series C complete molded case circuit breaker |
| Catalog Number | FDC3150L |
| UPC | 786679450246 |
| Product Length/Depth | 3.38 in |
| Product Height | 4.13 in |
| Product Width | 4.13 in |
| Product Weight | 4.5 lb |
| Certifications | UL Listed |
PRODUCT SPECIFICATIONS
| Amperage Rating | 150 A |
| Voltage rating | 600 Vac, 250 Vdc |
| Trip Type | T186 |
| Circuit breaker type | FDC |
| Circuit breaker frame type | Complete breaker |
| Series | Series C |
| Terminals | Line and load |
| Frame | F |
| Frequency rating | 50/60 Hz |
| Interrupt rating | 200 kAIC at 240 Vac 100 kAIC at 480 Vac |
| Number of poles | Three-pole |
