Description
GENERAL
| Application | For Joining A Range Of Cable, Parallel Or At Right Angles To Rod Or Tube, Direct Burial Cable, Fence Post |
| Catalog Number | GAR204C |
| Installation Torque Recommended in-lb | 240 LBS/in |
| Material | Copper Alloy |
| Material - Hardware | DURIUM™ Silicon Bronze |
| Plated | No |
| Plating Type | Bright Dipped |
| Product Family | Grounding and Bonding Connectors>Copper Mechanical Grounding Connectors>Cable(s) to Ground Rod/Pipe/Tube (GAR/GD/GK)>Single Conductor(GAR) |
| Product Type | Mechanical |
| Sub Brand | MECHANICAL CONNECTOR |
| Type | GAR |
| U Bolt Type | 267 |
| UPC | 781810236208 |
| UPC 14 Digit GTIN | 00781810236208 |
DIMENSIONS
| Dimension - B Length inch | 3.50 in |
| Dimension - Height fraction | 5-5/8 in |
| Dimension - Height inch | 5.63 in |
| Dimension - Height mm | 143 mm |
| Dimension - L Length Overall mm | 33 mm |
| Dimension - Length Overall inch | 1.31 in |
| Dimension - Outside Diameter inch | 3.50 in |
| Dimension - Width fraction | 4-3/4 in |
| Dimension - Width inch | 4.81 in |
| Dimension - Width mm | 122 mm |
| Package Height | 0 in |
| Package Length | 0 in |
| Package Weight | 0 lb |
| Package Width | 0 in |
CONDUCTOR RELATED
| Conductor - Copper Solid Size | 8 AWG;7 AWG;6 AWG;5 AWG;4 AWG;3 AWG |
| Conductor - Copper Solid Size Range | 8 AWG-4 AWG |
| Conductor - Copper Str Size | 9 AWG;8 AWG;7 AWG;6 AWG;5 AWG;4 AWG |
| Conductor - Copper Str Size Range | 9 AWG - 4 AWG |
| Conductor - Copper Tube Std Size | 3 IPS IPS |
| Conductor - Copper Tube Std Size Range | 3 IPS IPS |
| Conductor - Pipe or Round Tube Size | 3 in |
| Conductor - Rod Size | 3 - 3.5 in |
| Conductor - Rod Size Range | 3 in-3 1/2 in |
| Conductor Type | CU C Solid-Size CU C Str-Size CU Tube Std-Size Rod-Size |
CERTIFICATIONS AND COMPLIANCE
| Buy America(n) Qualified | Contact Manufacturer |
| Certification - CSA Approved | Yes |
| Certification - cULus | No |
| Certification - ETL | No |
| Certification - UL Listed Direct Burial | Yes |
| Certification - UL Recognized | No |
| Industry Standard(s) | UL467 |
| Standards - Industry Standards Met | UL467 |
| Standards - RoHS Compliance Status | EX |
| UL Listed | Yes |
FORCE RELATED
| Installation Torque Recommended in-lb | 240 LBS/in |
LOGISTICS
| Carton Quantity | 20 |
| Minimum Pack Quantity | 1 |
| Pallet Quantity | 1040 |
