GHBGFEP1030 - Eaton Cutler Hammer - 30A Single-Pole Circuit Breakers
Eaton Series C complete molded case circuit breaker, G-frame, GHB, Fixed thermal, fixed magnetic trip type, Single-pole, 30A, 480Y/277 Vac, 125/250 Vdc, 14 kAIC at 277 Vac, 50/60 Hz
GENERAL SPECIFICATIONS
| Product Name |
Eaton Series C complete molded case circuit breaker |
| Catalog Number |
GHBGFEP1030 |
| UPC |
786679067444 |
| Product Length/Depth |
2.63 in |
| Product Height |
4 in |
| Product Width |
1 in |
| Product Weight |
1.45 lb |
| Certifications |
UL Listed |
| Product Type |
Molded case circuit breaker |
PRODUCT SPECIFICATIONS
| Amperage Rating |
30 A |
| Voltage rating |
480Y/277 Vac, 125/250 Vdc |
| Trip Type |
T186 |
| Circuit breaker type |
GHB |
| Series |
Series C |
| Frame |
G |
| Frequency rating |
50/60 Hz |
| Interrupt rating |
14 kAIC at 277 Vac |
| Number of poles |
Single-pole |
PRODUCT DATASHEET
GHBGFEP1030
