Description
GENERAL
| Application | For Raised Floor Systems |
| Catalog Number | GP64526G1 |
| Installation Torque Recommended in-lb | 240 LBS/in |
| Material | Copper Alloy, Cast |
| Material - Hardware | DURIUM™ Silicon Bronze |
| Pedestal Type | Round;Square |
| Plated | No |
| Plating Type | Unplated |
| Product Family | Grounding and Bonding Connectors>Copper Mechanical Grounding Connectors>Pedestal Raised Floor Ground Clamp |
| Product Type | Mechanical |
| Sub Brand | MECHANICAL CONNECTOR |
| Type | GP-G1 |
| U Bolt Type | UB222 |
| UPC | 781810828014 |
| UPC 14 Digit GTIN | 00781810828014 |
DIMENSIONS
| Bolt Size | 3/8 in |
| Dimension - B Length inch | 1.50 in |
| Dimension - Height mm | 0 mm |
| Dimension - L Length Overall mm | 43 mm |
| Dimension - Length Overall inch | 1.69 in |
| Dimension - Width inch | 2.38 in |
| Dimension - Width mm | 60 mm |
| Package Height | 0 in |
| Package Length | 0 in |
| Package Weight | 0 lb |
| Package Width | 0 in |
CONDUCTOR RELATED
| Conductor - Copper Solid Size Range | 4 AWG |
| Conductor - Copper Str Size Range | 2/0 AWG |
| Conductor Size | #4 AWG Sol - 2/0 AWG Str |
| Conductor Type | CU C Str-Size |
| Number of Conductors | 1;2 |
CERTIFICATIONS AND COMPLIANCE
| Buy America(n) Qualified | Contact Manufacturer |
| Certification - CSA Approved | No |
| Certification - UL Listed Direct Burial | No |
| Industry Standard(s) | UL467 |
| Standards - Industry Standards Met | UL467 |
| Standards - RoHS Compliance Status | EX |
| UL Listed | Yes |
FORCE RELATED
| Installation Torque Recommended in-lb | 240 LBS/in |
LOGISTICS
| Carton Quantity | 12 |
| Minimum Pack Quantity | 1 |
| Pallet Quantity | 2400 |
