GRL100 - Appleton - (2) 1" Hubs Malleable Type GRL Explosion-Proof Conduit Outlet Box
A rigid conduit elbow, 1" in size, used to create smooth directional changes in conduit runs. Helps maintain NEC bend radius while offering high mechanical strength. Common in both hazardous and general-purpose electrical installations.
GENERAL SPECIFICATIONS
- NEC/CEC Certifications and Compliances
- GR/GRF: Class I, Division 1 and 2, Groups B, C, D; Class II, Division 1 and 2, Groups E, F, G; Class III; NEMA 3, 4, 4X; Class 1, Zone 1 and 2, IIA, IIB
- NEC/CEC Certifications and Compliances
- GRTS: Class I, Division 1 and 2, Groups B, C, D; Class II, Division 1 and 2, Groups E, F, G; Class III; NEMA 3, 4, 4X; Class 1, Zone 1 and 2, IIA, IIB, IP66 (without drain)
- Temperature Ranges
- GR/GRF: Ambient temperature range -25 degC to +40 degC.
- Temperature Ranges
- GRTS: Ambient temperature range without drain -40 degC to +60 degC (with drain -25 degC to +40 degC).
- Standard Materials and Finishes
- Ductile iron body with triple-coat finish (1) zinc electroplate, (2) chromate, and (3) epoxy powder coat; copperfree (4/10 of 1% max.) aluminum body and cover with epoxy powder coat
- Options
- GR and GRF: Ductile iron body and cover and the conduit outlet box without a cover is available. GRTS: factory installed drain and terminal blocks.
