Description
GTK03 - Schneider Electric - 30mm Square D Twist to Release Emergency Stop Button
The Square D(TM) by Schneider Electric brand Heavy Duty Safety Switch is designed to be tough, reliable and provide exceptional performance in the most grueling conditions. F Series safety switches provide significantly higher levels of mechanical endurance than NEMA KS-1 or UL98 standards require. All heavy duty safety switches feature a quick-make, quick-break operating mechanism, a dual cover interlock and a color-coded indicator handle. This Square D heavy duty safety switch grounding bar comes in 30A and 60A. This grounding bar accepts AWG gauges of AWG 12 (CU), AWG 10 (AL), and AWG 4 (AL/CU). This product comes with an 18 month warranty. This heavy duty safety switch grounding bar by Square D has a rated current of 30A and 60A and is rated ofr an AWG gauge of AWG 12, copper
GENERAL SPECIFICATIONS
| Range of Product | Square D |
|---|---|
| Product or Component Type | Safety switch grounding bar |
| Series name | Heavy duty |
| Line Rated Current | 30 A F1 30 A F5 30 A F7 60 A F1 60 A F3 60 A F5 60 A F7 |
|---|---|
| AWG gauge | AWG 12 copper AWG 10 aluminium AWG 4 copper or aluminium |
| Width | 1.054 in (26.772 mm) |
| Height | 0.437 in (11.100 mm) |
| Depth | 0.312 in (7.925 mm) |
| Tightening torque | 20 lbf.in (2.3 N.m) (AWG 14...AWG 10) 20 lbf.in (2.3 N.m) (AWG 12...AWG 10) 25 lbf.in (2.8 N.m) (AWG 8) 35 lbf.in (4.0 N.m) (AWG 6...AWG 4) 25 lbf.in (2.8 N.m) (2 x AWG 14...2 x AWG 10) 25 lbf.in (2.8 N.m) (2 x AWG 10...2 x AWG 10) |
| Category | US10DE100058 |
|---|---|
| Discount Schedule | 0DE1 |
| GTIN | 785901421818 |
| Returnability | Yes |
| Country of origin | US |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 0.30 in (0.762 cm) |
| Package 1 Width | 0.60 in (1.524 cm) |
| Package 1 Length | 1.10 in (2.794 cm) |
| Package 1 Weight | 0.80 oz (22.68 g) |
PRODUCT DATASHEET
