GTK0610 - Schneider Electric - Square D Emergency Stop Push Button
The Square D™ by Schneider Electric brand Heavy Duty Safety Switch is designed to be tough, reliable and provide exceptional performance in the most grueling conditions. F Series safety switches provide significantly higher levels of mechanical endurance than NEMA KS-1 or UL98 standards require. All heavy duty safety switches feature a quick-make, quick-break operating mechanism, a dual cover interlock and a color-coded indicator handle. This Square D heavy duty safety switch grounding bar comes in 30A and 60A. This grounding bar accepts AWG gauges of AWG 12 (CU), AWG 10 (AL), and AWG 4 (AL/CU). This product comes with an 18 month warranty. This heavy duty safety switch grounding bar by Square D has a rated current of 60A and 100A and is rated ofr an AWG gauge of AWG 2, copper or aluminium
GENERAL SPECIFICATIONS
| Range of Product | Square D |
|---|---|
| Product or Component Type | Safety switch grounding bar |
| Series name | Heavy duty |
| Line Rated Current | 60 A F1 60 A F3 60 A F5 60 A F7 100 A F2 100 A F7 |
|---|---|
| AWG gauge | AWG 2 copper or aluminium |
| Width | 3.180 in (80.772 mm) |
| Height | 1.405 in (35.687 mm) |
| Depth | 0.625 in (15.875 mm) |
| Tightening torque | 20 lbf.in (2.3 N.m) (AWG 14...AWG 10) 25 lbf.in (2.8 N.m) (AWG 8) 35 lbf.in (4.0 N.m) (AWG 6...AWG 4) 50 lbf.in (5.6 N.m) (AWG 3...AWG 1/0) |
| Category | US10DE100058 |
|---|---|
| Discount Schedule | 0DE1 |
| GTIN | 785901751380 |
| Returnability | Yes |
| Country of origin | US |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 1.00 in (2.540 cm) |
| Package 1 Width | 3.80 in (9.652 cm) |
| Package 1 Length | 3.90 in (9.906 cm) |
| Package 1 Weight | 2.400 oz (68.039 g) |
| Unit Type of Package 2 | CAR |
| Number of Units in Package 2 | 5 |
| Package 2 Height | 3.80 in (9.652 cm) |
| Package 2 Width | 4.40 in (11.176 cm) |
| Package 2 Length | 5.40 in (13.716 cm) |
| Package 2 Weight | 14.880 oz (421.841 g) |
| Unit Type of Package 3 | PAL |
| Number of Units in Package 3 | 2340 |
| Package 3 Height | 40.00 in (101.600 cm) |
| Package 3 Width | 40.00 in (101.600 cm) |
| Package 3 Length | 48.00 in (121.920 cm) |
| Package 3 Weight | 436.000 lb(US) (197.766 kg) |
