HBL2129 - Hubbell Wiring Device-Kellems - NEMA Nylon Convenience Adapter
Nylon Convenience Adapter, NEMA L5-20P To NEMA 5-15R
- Male Blade End
- Female Slot End
GENERAL SPECIFICATIONS
| Application |
Locking Male to Straight Blade Female |
| Catalog Number |
HBL2129 |
| Color |
White |
| Environmental Conditions |
Indoor Dry Unless Protected By Additional Means |
| EU RoHS Indicator |
No |
| Item Type |
Plug-In Adapter |
| Material |
Thermoplastic |
| Material - Mounting Hardware |
Plug-In |
| Number Of Poles |
2-No |
| OEM Brand Name |
Hubbell Wiring Device-Kellems |
| Specifications |
- Female End - 5-20R, 20A 125V
- Male End - L5-20P, 20A 125V
- Product Type - Nylon Convenience Adapters
|
| UPC |
783585809014 |
Dimensions
| Display Size |
Standard Sized Product |
Electrical Classifications
| Amperage Rating |
15 A |
| Connectivity |
Plug-In |
| Current / Amperage Rating |
15 A |
| Current Rating |
15 A |
| Phase |
Single Phase |
| Voltage Rating |
125 VAC |
| Wattage |
2500 |
Driver Related
|
Number Of Wires
|
3-Wire Grounding |
Logistics
|
Carton Quantity
|
20 |
| Pallet Quantity |
2720 |
PRODUCT DATASHEET
Wiring HBL2129 Specification Sheet
