HBL8432C - Hubbell Wiring Device-Kellems 30A 250V 3 Pole 4 Wire Plug Straight Blade Devices
Roll over image to zoom in Click on image to zoom
HBL8432C - Hubbell Wiring Device-Kellems 30A 250V 3 Pole 4 Wire Plug Straight Blade Devices

HBL8432C - Hubbell Wiring Device-Kellems 30A 250V 3 Pole 4 Wire Plug Straight Blade Devices

HubbellSKU: HUBHBL8432C
Price:
$100.87
Stock:
Sold out

Description

HBL8432C - Hubbell Wiring Device-Kellems 30A 250V 3 Pole 4 Wire Plug Straight Blade Devices

Straight Blade Devices, Plug Industrial Grade, 3-Pole 4-Wire Grounding, 30A 3 Phase 250V AC, 15-30P, Single Pack.

  • Catalog number, ratings and certifications molded in face
  • Gripping ribs provide secure gripping area
  • Supertough nylon housing

GENERAL SPECIFICATION

Catalog Number HBL8432C
EU RoHS Indicator Contact Manufacturer
Number Of Poles 3-Pole
OEM Brand Name Hubbell Wiring Device-Kellems
Operating Temperature Maximum continuous 75°C and minimum -40°C without Impact
Performance



  • Electrical: Current Interrupting: Certified for current interrupting at full rated current
  • Dielectric Voltage : Withstands 2,000V minimum
  • Mechanical: Terminal Accommodation: #12 AWG through #4 AWG copper wire only
  • Terminal Identification :Terminals identified in accordance with UL 498 and CSA
  • Environmental: Flammability: UL 94 HB
  • IP Suitability: IP20
  • Operating Temperatures: Maximum continuous 75°C
  • minimum -40°C (w/o impact)


Series Extra Heavy Duty
Style Grounding
Type Plug
UPC 783585015415



Dimensions

Weight 0.85 lb



Electrical Ratings

Amperage Rating 30 A
Current / Amperage Rating 30 A
Current Rating 30 A
Dielectric Strength Withstands 2,000V minimum
Voltage Rating 250 VAC
Voltage Rating Description 250 VAC



Conductor Related

Number Of Wires 4-Wire
Wire Size #12 AWG to #4 AWG



Logistics

Carton Quantity 5
Pallet Quantity 765



PRODUCT DATASHEET

Wiring HBL8432C Specification Sheet
