HBL9309 - Hubbell Wiring Device-Kellems 30A 125V 2 Pole 3 Wire Plug Straight Blade Devices
Straight Blade Devices, Male Plug, Nylon, Heavy Duty, Industrial/Commercial Grade, Angled, 2-Pole 3-Wire Grounding, 30A 125V, 5-30P, Black, Single Pack.
- Nylon
- Heavy Duty
- Industrial/Commercial Grade
GENERAL SPECIFICATION
| Catalog Number |
HBL9309 |
| Color |
Black |
| EU RoHS Indicator |
Contact Manufacturer |
| Horsepower - Maximum |
2 |
| OEM Brand Name |
Hubbell Wiring Device-Kellems |
| Operating Temperature |
Maximum continuous 75°C and minimum -40°C without Impact |
| Performance |
- Electrical - Current Interrupting - Certified for current interrupting at full rated current
- Electrical - Dielectric Voltage - Withstands 2,000V minimum
- Environmental - Flammability - UL 94 V-2
- Environmental - IP Suitability - IP20
- Environmental - Operating Temperatures - Maximum continuous 75°C minimum -40°C (w/o impact)
- Mechanical - Product Identification - Ratings are a permanent part of the device
- Mechanical - Terminal Accommodation - #12-#4 AWG copper stranded or solid conductor only
- Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
|
| Series |
Extra Heavy Duty |
| Specifications |
- Blade Holder - Reinforced Thermoplastic Polyester
- Box Terminals - Brass
- Cord Clamp - Reinforced Thermoplastic Polyester
- Housing - Supertough Nylon
- Terminal Retainer - Reinforced Thermoplastic Polyester
|
| Style |
Grounding |
| Type |
Plug |
| UPC |
783585015224 |
Dimensions
| Dimensions |
4.34 in x 2.75 in x 1.88 in |
| Height |
1.88 in |
| Length |
4.34 in |
| Weight |
0.55 lb |
| Width |
2.75 in |
Electrical Ratings
| Amperage Rating |
30 A |
| Current / Amperage Rating |
30 A |
| Current Rating |
30 A |
| Dielectric Strength |
Withstands 2,000V minimum |
| Voltage Rating |
125 V |
| Voltage Rating Description |
125 V |
| Wattage |
3750 W |
Conductor Related
| Number Of Poles |
2-Pole |
| Number Of Wires |
3-Wire |
| Wire Size |
#12 AWG to #4 AWG |
Operational
| Horsepower - Maximum |
2 |
| Operating Temperature |
Maximum continuous 75°C and minimum -40°C without Impact |
| Performance |
- Electrical - Current Interrupting - Certified for current interrupting at full rated current
- Electrical - Dielectric Voltage - Withstands 2,000V minimum
- Environmental - Flammability - UL 94 V-2
- Environmental - IP Suitability - IP20
- Environmental - Operating Temperatures - Maximum continuous 75°C minimum -40°C (w/o impact)
- Mechanical - Product Identification - Ratings are a permanent part of the device
- Mechanical - Terminal Accommodation - #12-#4 AWG copper stranded or solid conductor only
- Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
|
Logistics
| Carton Quantity |
10 |
| Pallet Quantity |
1360 |
