HBLDS60100RS - Hubbell Wiring Device-Kellems 60A 600V 3 Pole Disconnect Switches Replacement Switch
Switches and Lighting Controls, Industrial Grade, Disconnect Switches, Replacement Switch, Three Pole, 60A 600V AC, Screw Terminals, Gray
NEC section 430.102(B) requires each motor controller to have a disconnect within line of sight from the motor and driven equipment. Hubbell’s Circuit-Lock® Unfused Disconnect Switches are UL listed as a manual motor controller and also “suitable as a motor disconnect” and meet these code requirements.
- Industrial Grade
- Disconnect Switches
- Replacement Switch
- Three Pole
GENERAL SPECIFICATIONS
| Catalog Number |
HBLDS60100RS |
| EU RoHS Indicator |
No |
| Ingress Protection |
IP67 |
| Operating Temperature |
Maximum continuous 75°C and minimum -40°C without Impact |
| Performance |
- Electrical - Current Interrupting - Certified for current interrupting at full rated current
- Electrical - Dielectric Voltage - Withstand 3,000V AC
- Electrical - Max Working Voltage - 600V AC RMS
- Environmental - Flammability - UL94-5VA and V-0 classification
- Environmental - Ingress Protection - IP67 Suitability
- Environmental - Operating Temperatures - Max Continuous- 75 °C, Minimum -40 ° w/o Impact
- Mechanical - Impact Resistance - In accordance with UL746C
- Mechanical - Product Identification - Identification and ratings are a part of the external label and molded into the receptacle mount.
- Mechanical - Terminal Identification - Terminals identified in accordance with North American and International conventions
|
| Series |
Non-Fused;Fused |
| Specifications |
- Assembly Screws - Stainless Steel
- Gaskets - Neoprene
- Hinge Spring - Stainless Steel
- Interlock Items - Replacement Parts
|
| Style |
Replacement Switches |
| Type |
Accessories |
| UPC |
783585955216 |
Electrical Ratings
| Amperage Rating |
60/100 A |
| Current / Amperage Rating |
60/100 A |
| Dielectric Strength |
Withstands 3000V AC minimum |
Operational
| Operating Temperature
|
Maximum continuous 75°C and minimum -40°C without Impact |
| Performance |
- Electrical - Current Interrupting - Certified for current interrupting at full rated current
- Electrical - Dielectric Voltage - Withstand 3,000V AC
- Electrical - Max Working Voltage - 600V AC RMS
- Environmental - Flammability - UL94-5VA and V-0 classification
- Environmental - Ingress Protection - IP67 Suitability
- Environmental - Operating Temperatures - Max Continuous- 75 °C, Minimum -40 ° w/o Impact
- Mechanical - Impact Resistance - In accordance with UL746C
- Mechanical - Product Identification - Identification and ratings are a part of the external label and molded into the receptacle mount.
- Mechanical - Terminal Identification - Terminals identified in accordance with North American and International conventions
|
Logistics
PRODUCT DATASHEET
Wiring HBLDS60100RS Specification Sheet
