HFD3200L - Eaton Cutler-Hammer - Feed Thru 200 Amp 3 Pole 600 Volt Molded Case Circuit Breakers
Eaton Series C complete molded case circuit breaker, Series C, F-frame molded case circuit breaker, 200 A, Three-pole, Line and load terminals, Thermal magnetic trip
GENERAL SPECIFICATIONS
| Product Name | Eaton Series C complete molded case circuit breaker |
| Catalog Number | HFD3200L |
| UPC | 786679015469 |
| Product Length/Depth | 3.38 in |
| Product Height | 4.13 in |
| Product Width | 4.13 in |
| Product Weight | 4 lb |
| Certifications | UL Listed |
| Product Type | Molded case circuit breaker |
PRODUCT SPECIFICATIONS
| Amperage Rating | 200 A |
| Voltage rating | 600 Vac, 250 Vdc |
| Trip Type | T186 |
| Circuit breaker type | HFD |
| Circuit breaker frame type | Complete breaker |
| Series | Series C |
| Terminals | Line and load |
| Frame | F |
| Frequency rating | 50 to 60 Hz |
| Interrupt rating | 100 kAIC at 240 Vac 65 kAIC at 480 Vac |
| Number of poles | Three-pole |
