Description
HMCP003A0C - Eaton Cutler Hammer - 9-30 A 8" Molded Case Circuit Breaker Accessory Motor Circuit Protector
Eaton molded case circuit breaker accessory motor circuit protector, Motor circuit protector, 3 A, Three-pole, Frame J-K, 9-30 A, Series C, Non-aluminum
GENERAL SPECIFICATIONS
| Product Name | Eaton molded case circuit breaker, accessory motor circuit protector |
| Catalog Number | HMCP003A0C |
| UPC | 786679150795 |
| Product Length/Depth | 8 in |
| Product Height | 5 in |
| Product Width | 5 in |
| Product Weight | 4.5 lb |
| Certifications | UL Listed CSA Certified |
| Global Catalog | HMCP003A0C |
| Product Type | Molded case circuit breaker accessory |
PRODUCT SPECIFICATIONS
| Amperage Rating | 3 A |
| Frame size | Frame J-K |
| Magnetic trip range | 9-30 A |
| Series | Series C |
| Terminal material | Non-aluminum |
| Number of poles | Three-pole |
| Type | Motor circuit protector |
PRODUCT DATASHEET
