HMCP015E0C - Eaton Cutler Hammer - 45-150 A 8" Molded Case Circuit Breaker Accessory Motor Circuit Protector
The Eaton HMCP015E0C delivers 15 A protection with a magnetic trip range of 45–150 A within the same J-K frame, Series C motor protector configuration, using non-aluminum terminals. It’s UL- and CSA-listed for robust use in motor protection circuits.
GENERAL SPECIFICATIONS
| Product Name |
Eaton molded case circuit breaker accessory motor circuit protector
|
| Catalog Number |
HMCP015E0C
|
| UPC |
786679150818
|
| Product Length/Depth |
8 in
|
| Product Height |
5 in
|
| Product Width |
5 in
|
| Product Weight |
4.5 lb
|
| Certifications |
UL Listed
CSA Certified |
| Global Catalog |
HMCP015E0C
|
| Product Type |
Molded case circuit breaker accessory
|
PRODUCT SPECIFICATIONS
| Amperage Rating |
15 A
|
| Frame size |
Frame J-K
|
| Magnetic trip range |
45-150 A
|
| Series |
Series C
|
| Terminal material |
Non-aluminum
|
| Number of poles |
Three-pole
|
| Type |
Motor circuit protector
|
