Description
HMCPE015E0C - Eaton Cutler Hammer - 15A Three-Pole Motor Circuit Protector
Eaton molded case circuit breaker accessory motor protection, Motor circuit protector, 15 A, Three-pole, 480 V, Adjustable, Frame J-K, 45-150 A, 600 Y/347 V, Series G, Non-aluminum
GENERAL SPECIFICATIONS
| Product Name | Eaton molded case circuit breaker accessory motor protection |
| Catalog Number | HMCPE015E0C |
| UPC | 786679113653 |
| Product Length/Depth | 2.99 in |
| Product Height | 5.5 in |
| Product Width | 3 in |
| Product Weight | 3 lb |
| Compliances | Contact Manufacturer |
| Certifications | UL Listed CSA Certified |
| Global Catalog | HMCPE015E0C |
| Product Type | Molded case circuit breaker accessory |
PRODUCT SPECIFICATIONS
| Amperage Rating | 15 A |
| Voltage rating | 480 V |
| Trip Type | T98 |
| Frame size | Frame J-K |
| Magnetic trip range | 45-150 A |
| Voltage - max | 600 Y/347 V |
| Series | Series G |
| Terminal material | Non-aluminum |
| Number of poles | Three-pole |
| Type | Motor circuit protector |
