HOM2150 - Square D - 150A 120 240VAC Homeline Standard Plug In Mini Circuit Breaker 4 Pole 10kA AIR UL
Homeline miniature circuit breakers are engineered and designed for fast installation and superior circuit protection. Homeline circuit breakers are designed to plug into Homeline load centers to provide circuit protection. This circuit breaker provides standard circuit protection and is HACR rated. This 2 pole circuit breaker with plug in mounting is rated 150 A at 120/240 VAC. HOM breakers provide 10 kA breaking capacity. The electrical connections are box lugs that will accept 1 wires. The box lugs will accept a wire range of 4 AWG to 2/0 AWG copper or aluminum wire. HOM Homeline miniature circuit breakers are UL Listed.
GENERAL SPECIFICATIONS
Main
| Product |
Miniature circuit-breaker |
| Range |
Homeline |
| Current Rating |
150 A |
| Certifications |
UL Listed |
| Voltage Rating |
120/240 V AC |
| Mounting Type |
Plug-in |
| Number of Poles |
4P |
| Short Circuit Current Rating |
10 kA |
| Number of Spaces |
2 |
| Circuit Breaker Type |
Standard |
| Ratings |
HACR rated |
| Electrical Connection |
Box lugs |
| Wire Size |
1 x AWG 4...300 kcmil ( aluminium/copper ) |
Complementary
| Tightening torque |
35.4 lbf.in (4.0 N.m) (AWG 4...AWG 2/0) |
| Height |
3.13 in (79.50 mm) |
| Width |
2 in (50.8 mm) |
| Depth |
2.98 in (75.69 mm) |
Environment
| Ambient Air Temperature for Operation |
104 °F (40 °C) |
Ordering and shipping details
| Category |
US1DE3D00151 |
| Discount Schedule |
DE3D |
| GTIN |
785901065838 |
| Returnability |
Yes |
| Country of origin |
MX |
Packing Units
| Unit Type of Package 1 |
PCE |
| Nbr. of units in pkg. |
1 |
| Package 1 Height |
3.700 in (9.398 cm) |
| Package 1 Width |
3.300 in (8.382 cm) |
| Package 1 Length |
4.200 in (10.668 cm) |
| Package weight(Lbs) |
28.160 oz (798.322 g) |
| Unit Type of Package 2 |
CAR |
| Number of Units in Package 2 |
20 |
| Package 2 Height |
4.300 in (10.922 cm) |
| Package 2 Width |
15.000 in (38.100 cm) |
| Package 2 Length |
20.800 in (52.832 cm) |
| Package 2 Weight |
35.435 lb(US) (16.073 kg) |
| Unit Type of Package 3 |
PAL |
| Number of Units in Package 3 |
1728 |
| Package 3 Height |
43.500 in (110.490 cm) |
| Package 3 Width |
40.000 in (101.600 cm) |
| Package 3 Length |
48.000 in (121.920 cm) |
| Package 3 Weight |
3042.0003 lb(US) (1379.827 kg) |
PRODUCT DATASHEET
HOM2150
