Description
| Main | |
|---|---|
| Product | Miniature circuit-breaker |
| Range | Homeline |
| Current Rating | 150 A |
| Certifications | UL Listed |
| Voltage Rating | 120/240 V AC |
| Mounting Type | Plug-in |
| Number of Poles | 4P |
| Short Circuit Current Rating | 10 kA |
| Number of Spaces | 4 |
| Circuit Breaker Type | Standard |
| Ratings | HACR rated |
| Electrical Connection | Box lugs |
| Wire Size | 1 x 4 AWG...300 kcmil ( aluminium/copper ) |
| Complementary | |
| Tightening torque | 250.5 lbf.in (28.3 N.m) 0.1…0.2 in² (95…150 mm²) (4/0 AWG...250 kcmil) |
| Height | 5.39 in (136.91 mm) |
| Width | 3.98 in (101.09 mm) |
| Depth | 3.13 in (79.50 mm) |
| Environment | |
| Ambient Air Temperature for Operation | 104 °F (40 °C) |
| Ordering and shipping details | |
| Category | US1DE3D00144 |
| Discount Schedule | DE3D |
| GTIN | 785901296201 |
| Returnability | Yes |
| Country of origin | MX |
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Nbr. of units in pkg. | 1 |
| Package 1 Height | 5.700 in (14.478 cm) |
| Package 1 Width | 6.800 in (17.272 cm) |
| Package 1 Length | 7.700 in (19.558 cm) |
| Package weight(Lbs) | 2.961 lb(US) (1.343 kg) |
| Contractual warranty | |
| Warranty (in months) | 18 |
Product Datasheet
HOM2150BB
HOM2150BB
