HRK1020 - Schneider Electric - Square D Fuse Rejection Kit Safety Switch Series F5/F6 200A
Schneider Electric's Square D heavy duty safety switch is designed to be tough, reliable and provide exceptional performance in the most grueling conditions. All heavy duty safety switches feature a quick-make, quick-break operating mechanism, a dual cover interlock, and a color coded indicator handle. They also come with many field installable or factory installed accessories. This fuse rejection kit is field installable and limits the switch to only Class R fuses. It is for switches rated for up to 200A. One kit is required for a three pole switch. It is UL listed.
GENERAL SPECIFICATIONS
Main
| Product or Component Type |
Fuse rejection kit |
| Product destination |
Safety switch |
Complementary
| Fuse type |
R |
| Length |
0.88 in (22.35 mm) |
Ordering and shipping details
| Category |
US10DE100058 |
| Discount Schedule |
0DE1 |
| GTIN |
785901011088 |
| Returnability |
Yes |
| Country of origin |
US |
Packing Units
| Unit Type of Package 1 |
PCE |
| Number of Units in Package 1 |
1 |
| Package 1 Height |
2.80 in (7.112 cm) |
| Package 1 Width |
0.20 in (0.508 cm) |
| Package 1 Length |
4.50 in (11.430 cm) |
| Package 1 Weight |
0.992 oz (28.123 g) |
| Unit Type of Package 2 |
CAR |
| Number of Units in Package 2 |
10 |
| Package 2 Height |
3.70 in (9.398 cm) |
| Package 2 Width |
6.30 in (16.002 cm) |
| Package 2 Length |
6.80 in (17.272 cm) |
| Package 2 Weight |
12.800 oz (362.874 g) |
| Unit Type of Package 3 |
PAL |
| Number of Units in Package 3 |
1200 |
| Package 3 Height |
40.00 in (101.600 cm) |
| Package 3 Width |
40.00 in (101.600 cm) |
| Package 3 Length |
48.00 in (121.920 cm) |
| Package 3 Weight |
96.0004 lb(US) (43.545 kg) |
