Description
General
| Actuator | Push Buttons |
| Catalog Number | CPB21 |
| Color | |
| Contact Configuration | Momentary |
| Enclosure Type | NEMA 4X |
| Environmental Conditions | Indoor and Outdoor |
| EU RoHS Indicator | |
| Indicator(s) Type | None |
| Ingress Protection | IP55 |
| Material - Mounting Hardware | Cable Mounted |
| OEM Brand Name | Hubbell Wiring Device-Kellems |
| Operating Temperature | Maximum continuous 75°C and minimum -40°C without Impact |
| Performance | Environmental - Operating Temperatures - Max Continuous 75°C, Minimum -40° w/o Impact |
| Series | Compact |
| Style | Two Button |
| Type | Single Speed |
| UPC | 783585106854 |
Dimensions
| Dimensions | 9.13 in × 1.06 in × 2.38 in |
| Display Size | Compact |
| Height | 2.38 in |
| Length | 9.13 in |
| Weight | 0.75 lb |
| Width | 1.06 in |
Electrical Ratings
| Amperage Rating | 120V AC - 6A, 240V AC 3HP PF-3A, 125V DC - 1.1A, Inductive 250V - .55A |
| Connectivity | Terminal Screws |
| Contact Rating | Pilot Duty Only |
| Phase | Single Phase |
Certifications And Compliance
| Environmental Conditions | Indoor and Outdoor |
| EU RoHS Indicator | |
| Industry Standard(s) | UL Listed |
| Nema Rating | NEMA 4X |
Operational
| Actuator | Push Buttons |
| Indicator(s) Type | None |
| Operating Temperature | Maximum continuous 75°C and minimum -40°C without Impact |
| Performance | Environmental - Operating Temperatures - Max Continuous 75°C, Minimum -40° w/o Impact |
Logistics
| Carton Quantity | 25 |
| Pallet Quantity | 1500 |
