| Application |
Standard Toggle |
| Catalog Number |
HBL1379 |
| Color |
Aluminum |
| Enclosure Type |
NEMA 1 |
| Environmental Conditions |
Indoor Dry Unless Protected By Additional Means |
| EU RoHS Indicator |
— |
| Horsepower - Maximum |
15 |
| Load Capacity |
Inductive |
| Material - Mounting Hardware |
Screw Mounting |
| OEM Brand Name |
Hubbell Wiring Device-Kellems |
| Operating Cycles |
10,000 Cycles Minimum |
| Performance |
- Electrical - Dielectric Voltage - Min. 2,200V AC minimum for 1 minute
- Electrical - Electrical Life - Min. 6,000 Cycles at rated switch load
- Electrical - Max. Working Voltage - 600V AC RMS
- Environmental - Flammability - UL94HB/V0
- Environmental - Operating Temperature - Max. 75°C, Min. -40°C continuous without impact
- Mechanical - Mechanical Life - Min. 10,000 minimum cycles
- Mechanical - Switch Rating - 25 inch pounds
- Mechanical - Terminal Accommodations - #10 AWG Max
- Mechanical - Terminal Torque - 20 inch pounds
- Mechanical - Wire Type - Solid and stranded copper wire only
|
| Series |
Non-Fused |
| Specifications |
Enclosure Material - Aluminum |
| Style |
Standard Duty |
| Type |
Disconnect Switches |
| UPC |
783585690903 |
