| Application |
Heavy Duty Industrial and/or Washdown |
| Catalog Number |
HBLDS30 |
| Color |
Gray |
| Enclosure Type |
IP69K and UL Type 4X, 12 |
| Environmental Conditions |
Indoor and Outdoor |
| Horsepower - Maximum |
15 |
| Ingress Protection |
IP69K and UL NEMA Type 4X, 12 |
| Material - Mounting Hardware |
Stainless Steel Screw Mounting |
| Mounting Method |
External fully adjustable feet |
| Operating Cycles |
10,000 Cycles Minimum |
| Operating Temperature |
Maximum Continuous 75°C, Minimum -40°C |
| Performance |
- Current interrupting certified at full rated current & voltage.
- Dielectric voltage withstands 3000 VAC minimum.
- Maximum working voltage 600 VAC RMS.
- UL94-5VA and V0 material classification.
- UV resistant materials.
- Impact resistant per UL746C.
- Terminal identification complies with UL, CSA and international conventions.
|
| Series |
Non-Fused |
| Specifications |
- Base – Valox®
- Enclosure Gasket – Neoprene
- Handle – Valox®
- Shaft (Unfused) – Valox®
- Top – Valox®
|
| Style |
Heavy Duty |
| Type |
Disconnect Switches |
| UPC |
783585763002 |
