KA36150 - Square D - 150 Amp 600VAC 3 Pole Thermal Magnetic KA Frame I-Line Circuit Breaker
KA36150 is a Square D 3 Pole 150 Amp circuit breaker designed for 600VAC applications with a KA frame and I-Line style plug-in mounting.This thermal magnetic molded case circuit breaker provides reliable overcurrent protection with long-time and instantaneous trip functions. It features a 25kA interrupting rating at 480V, UL, CE, and CSA approvals, and is suitable for 3-phase electrical systems. The breaker is rated for operation at 40°C ambient temperature and mounts via plug-on I-Line style connection.
GENERAL SPECIFICATIONS
| Part Number | KA36150 |
| Manufacturer | Square D |
| Category | Circuit Breaker |
| Item Subcategory | Molded Case |
| Family | I-Line |
| Type | KA |
| Voltage | 600 |
| Amperage | 150 |
| Phase | 3 |
| Poles | 3 |
| AIC rating | 25kA@480V |
| Connection | I-Line Style Plug-In |
| Functions | LI - Long-Time and Instantaneous Trip |
| Frame Size | K Frame |
| Temp Rating | -13–158 °F (-25–70 °C) |
| Protection | Thermal Magnetic |
| UPC | 786679307748 |
| GTIN | 00786679307748 |
| Weight | 13 |
