| Conductor - AAAC 5005 Run |
77.47 (7) kcmil |
| Conductor - AAAC 5005 Run Range |
77.47 (7) kcmil |
| Conductor - AAAC 5005 Tap |
30.58 (7) kcmil;48.69 (7) kcmil;77.47 (7) kcmil |
| Conductor - AAAC 5005 Tap Range |
30.58 (7) kcmil-77.47 (7) kcmil |
| Conductor - AAAC 6201 Run |
77.47 (7) kcmil |
| Conductor - AAAC 6201 Run Range |
77.47 (7) kcmil |
| Conductor - AAAC 6201 Tap |
30.58 (7) kcmil;48.69 (7) kcmil;77.47 (7) kcmil |
| Conductor - AAAC 6201 Tap Range |
30.58 (7) kcmil-77.47 (7) kcmil |
| Conductor - ACSR Str Run |
3 (6/1) Swallow AWG;2 (6/1) Sparrow AWG;2 (7/1) Sparate AWG;1 (6/1) Robin AWG |
| Conductor - ACSR Str Run Range |
3 AWG - 1AWG |
| Conductor - ACSR Str Tap |
6 (6/1) Turkey AWG;5 (6/1) Thrush AWG;4 (6/1) Swan AWG;4 (7/1) Swanate AWG;3 (6/1) Swallow AWG;2 (6/1) Sparrow AWG;2 (7/1) Sparate AWG;1 (6/1) Robin AWG |
| Conductor - ACSR Str Tap Range |
6 AWG - 1 AWG |
| Conductor - AL Str Run |
2 AWG;1 AWG;1/0 AWG |
| Conductor - AL Str Run Range |
2 AWG - 1/0 AWG |
| Conductor - AL Str Tap |
10 AWG;8 AWG;6 AWG;4 AWG;3 AWG;2 AWG;1 AWG;1/0 AWG |
| Conductor - AL Str Tap Range |
10 AWG - 1/0 AWG |
| Conductor - Copper Solid Run |
22 |
| Conductor - Copper Solid Run Range |
22 |
| Conductor - Copper Solid Tap |
22 |
| Conductor - Copper Solid Tap Range |
22 |
| Conductor - Copper Str Run |
2 AWG;1 AWG;1/0 |
| Conductor - Copper Str Run Range |
2 AWG - 1/0 AWG |
| Conductor - Copper Str Tap |
10 AWG;9 AWG;8 AWG;7 AWG;6 AWG;5 AWG;4 AWG;3 AWG;2 AWG;1 AWG;1/0 |
| Conductor - Copper Str Tap Range |
10 AWG - 1/0 AWG |
| Conductor - Galvanized Steel Str Size |
3/8 (7) in |
| Conductor - Galvanized Steel Str Size Range |
3/8 (7) in |
| Conductor Type |
CU C Solid-Run CU C Str-Run AL C Str-Run AAAC C 5005-Run AAAC C 6201-Run ACSR C Str-Run CU C Solid-Tap CU C Str-Tap AL C Str-Tap AAAC C 5005-Tap AAAC C 6201-Tap ACSR C Str-Tap GAL Steel C Str-Size |
