Description
| Main | |
|---|---|
| Range | TeSysTeSys Deca |
| Product name | TeSys Deca |
| Product or Component Type | Time delay auxiliary contact block |
| Range compatibility | TeSys Deca CADTeSys Deca LC1DTeSys F LC1FTeSys F CR1F |
| Mounting Location | Front |
| Pole contact composition | 1 NO + 1 NC |
| Contacts operation | Time delay |
| Timer type | On delay |
| Time delay range | 10...180 s |
| [Ue] rated operational voltage | 690 V AC 25...400 Hz |
| [Ie] rated operational current | 6 A at 120 V AC-151.04 A at 690 V AC-150.55 A at 125 V DC-130.1 A at 600 V DC-13 |
| [Ui] rated insulation voltage | 690 V IEC 60947-5-1600 V UL 60947-5-1600 V CSA C22.2 No 60947-5-1 |
| [Ith] conventional free air thermal current | 10 A (at 140 °F (60 °C)) |
| Standards | EN/IEC 60947-5-1UL 60947-5-1CSA C22.2 No 60947-5-1GB/T 14048.5EN 50012IEC 60335-1:Clause 30.2IEC 60335-2-40:Annex JJUL 60335-2-40:Annex JJ |
| Product Certifications | IECEE CB SchemeULCSACCCEACUKCA |
| Complementary | |
| Irms rated making capacity | 140 A at <= 690 V AC conforming to IEC 60947-5-1250 A at <= 690 V DC conforming to IEC 60947-5-1 |
| Permissible short-time rating | 100 A 140 °F (60 °C) 1 s120 A 140 °F (60 °C) 500 ms140 A 140 °F (60 °C) 100 ms |
| Protection type | GG fuse 10 A |
| Mechanical durability | 5 Mcycles |
| Minimum switching current | 5 mA |
| Minimum switching voltage | 17 V |
| Non-overlap time | 1.5 ms on de-energisation no overlap between NC and NO contact1.5 ms on energisation no overlap between NC and NO contact |
| Insulation resistance | > 10 MOhm |
| Connections - terminals | screw clamp terminals 1 0.002…0.004 in² (1…2.5 mm²)flexible with cable end screw clamp terminals 1 0.002…0.004 in² (1…2.5 mm²)flexible without cable end screw clamp terminals 2 0.002…0.004 in² (1…2.5 mm²)flexible with cable end screw clamp terminals 2 0.002…0.004 in² (1…2.5 mm²)flexible without cable end screw clamp terminals 1 0.002…0.004 in² (1…2.5 mm²)rigid screw clamp terminals 2 0.002…0.004 in² (1…2.5 mm²)rigid screw clamp terminals |
| Tightening torque | 15.05 lbf.in (1.7 N.m) flat Ø 6 mm 15.05 lbf.in (1.7 N.m) Philips No 2 15.05 lbf.in (1.7 N.m) pozidriv No 2 |
| Height | 1.9 in (48 mm) |
| Width | 1.7 in (44 mm) |
| Depth | 2.4 in (61 mm) |
| color | Dark grey |
| Environment | |
| Environmental characteristic | Normal environment |
| IP degree of protection | IP20 conforming to IEC 60529 |
| Protective treatment | TH IEC 60068 |
| Ambient Air Temperature for Storage | -76…176 °F (-60…80 °C) |
| Ambient Air Temperature for Operation | -40…158 °F (-40…70 °C) |
| Operating altitude | 9842.52 ft (3000 m) |
| Ordering and shipping details | |
| Category | US1CTR121253 |
| Discount Schedule | CTR1 |
| GTIN | 3389110385977 |
| Returnability | Yes |
| Country of origin | FR |
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Nbr. of units in pkg. | 1 |
| Package 1 Height | 2.05 in (5.2 cm) |
| Package 1 Width | 2.6 in (6.5 cm) |
| Package 1 Length | 2.0 in (5.0 cm) |
| Package weight(Lbs) | 2.6 oz (74.0 g) |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 10 |
| Package 2 Height | 2.05 in (5.2 cm) |
| Package 2 Width | 5.5 in (14.0 cm) |
| Package 2 Length | 9.4 in (24.0 cm) |
| Package 2 Weight | 26.5 oz (750.0 g) |
| Unit Type of Package 3 | S03 |
| Number of Units in Package 3 | 140 |
| Package 3 Height | 11.8 in (30.0 cm) |
| Package 3 Width | 11.8 in (30.0 cm) |
| Package 3 Length | 15.7 in (40.0 cm) |
| Package 3 Weight | 24.224 lb(US) (10.988 kg) |
| Contractual warranty | |
| Warranty (in months) | 18 |
