Description
| Main | |
|---|---|
| Product or Component Type | Circuit breaker |
| Trip Unit Technology | Thermal-magnetic |
| Complementary | |
| Line Rated Current | 400 A |
| Number of Poles | 3P |
| Mounting Mode | Unit mount |
| Magnetic Hold Current | 2000 A |
| Magnetic Tripping Current | 4000 A |
| Electrical connection | Lugs, loadLugs, line |
| Terminal identifier | AL400LA |
| Tightening torque | 115.06 lbf.in (13 N.m) 0.07…0.5 in² (42…304 mm²) (AWG 1...600 kcmil)115.06 lbf.in (13 N.m) 0.07…0.2 in² (42…127 mm²) (AWG 1...250 kcmil) |
| Height | 11 in (279.4 mm) |
| Width | 6 in (152.4 mm) |
| Depth | 5.84 in (148.34 mm) |
| Circuit breaker application | HACR rated |
| Environment | |
| Certifications | IECCSAUL Listed |
| Ordering and shipping details | |
| Category | US10DE200935 |
| Discount Schedule | 0DE2 |
| GTIN | 785901339496 |
| Returnability | Yes |
| Country of origin | MX |
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Nbr. of units in pkg. | 1 |
| Package 1 Height | 8.900 in (22.606 cm) |
| Package 1 Width | 11.500 in (29.210 cm) |
| Package 1 Length | 17.400 in (44.196 cm) |
| Package weight(Lbs) | 16.839 lb(US) (7.638 kg) |
| Contractual warranty | |
| Warranty (in months) | 18 |
Product Datasheet
LAL364001021
LAL364001021
