Description
LB75A - Appleton - 3/4" Form 85 Type LB Aluminum Conduit Body
An aluminum LB conduit body for 2½" conduit, built for large-capacity cable runs. Offers easy access for splicing or pulling wires. Rust-resistant body ensures long service life. Common in utility or outdoor conduit systems.
GENERAL SPECIFICATIONS
- NEC/CEC Certifications and Compliances
- Suitable for use in Class I, Division 2 hazardous locations per NEC 501.10(B)(4)
- 1/2 thru 2 Standard Materials and Finishes
- Pressure cast copperfree (max. 4/10 of 1%) aluminum bodies and covers with epoxy powder coat; stamped aluminum or covers with natural finish; malleable iron covers; neoprene or composition fiber gaskets
- 2-1/1 thru 4 Standard Materials and Finishes
- Sand cast copperfree (max. 4/10 of 1%) aluminum bodies and covers with epoxy powder coat; stamped aluminum or covers with natural finish; malleable iron covers; neoprene or composition fiber gaskets
- Optional Finishes
- PVC coating available on select bodies and covers. See catalog pages for details
PRODUCT DATASHEET
