| SKU |
LP-CC-1-1/8 |
| descriptionLabel |
Eaton Bussmann Series Class CC fuse, LP-CC, time-delay, dual-element current limiting fuse, 0.5 A, rejection style fuse, interrupting rating of 200kA at 600Vac and 20kA at 300Vdc |
| Product Name |
Eaton Bussmann series LP-CC fuse |
| Catalog Number |
LP-CC-1-1/8 |
| UPC |
051712180443 |
| EAN |
5027590172967 |
| Product Length/Depth |
0.41 in |
| Product Height |
1.5 in |
| Product Width |
0.41 in |
| Product Weight |
0.15 lb |
| Warranty |
Not Applicable |
| Compliances |
CE Marked RoHS Compliant |
| Certifications |
UL Listed CSA Certified |
| Product Type |
Fuse |
| Amperage Rating |
1.125A |
| Number of elements |
Dual |
| Class |
Class CC |
| Interrupt rating |
200 kAIC at 600 Vac 20 kAIC at 300 Vdc |
| Fuse indicator |
Non-indicating |
| Connection |
Ferrule end x ferrule end |
| Response time |
12 sec at 200% |
| Material |
Melamine tube |
| Packaging type |
Standard |
| Quantity |
10 |
| Voltage rating |
600 Vac, 300 Vdc |
| Type |
Current-limiting time-delay fuse |
| Special features |
Rejection style |
| Application |
Specialized circuits and industrial control |
