LP-CC-4-1/2 - Bussmann - 4-1/2 Amp 600 Vac Class CC Time-delay / Low-Peak Fuse

BussmannSKU: BUSLP-CC-4-1/2
Price:
$11.52
Stock:
Sold out

We source most out-of-stock items - request a fast quote.

Description

LP-CC-4-1/2 - Eaton Bussmann Series - Eaton Bussmann series LP-CC fuse

SKU LP-CC-4
descriptionLabel Eaton Bussmann Series Class CC fuse, LP-CC, time-delay, dual-element current limiting fuse, 4 A, rejection style fuse, interrupting rating of 20 kA at 150 Vdc and 200 kA at 600 Vac
Product Name Eaton Bussmann series LP-CC fuse
Catalog Number LP-CC-4
UPC 051712180320
EAN 5704057051187
Product Length/Depth 1.5 in
Product Height 0.41 in
Product Width 0.41 in
Product Weight 0.15 lb
Warranty Not Applicable
Compliances CE Marked RoHS Compliant
Certifications UL Listed CSA Certified
Product Type Fuse
Amperage Rating 4 A
Number of elements Dual
Class Class CC
Interrupt rating 20 kAIC at 150 Vdc 200 kAIC at 600 Vac
Fuse indicator Non-indicating
Connection Ferrule end x ferrule end
Response time 12 sec at 200%
Material Melamine tube
Packaging type Standard
Quantity 10
Voltage rating 600 Vac, 150 Vdc
Type Current-limiting time-delay fuse
Special features Rejection style
Application Specialized circuits and industrial control
