Description
| Main | |
|---|---|
| Range | ComPact |
| Range of Product | ComPacT NSXm |
| Device short name | MX |
| Product or Component Type | Voltage release |
| Device Application | Control |
| Voltage release type | Opening coilShunt trip release |
| Control Type | Standard |
| [Uc] control circuit voltage | 24 V AC 50/60 Hz24 V DC |
| Range compatibility | ComPact ComPacT NSXmComPact ComPact NSXmPowerPact PowerPact B |
| Complementary | |
| Operating threshold | 0.7 Un opening |
| Response time | < 50 ms |
| Control signal type | ImpulseMaintained |
| Impulse duration | >= 20 ms |
| Auxiliary connection terminal | spring |
| Ordering and shipping details | |
| Category | US10DE201136 |
| Discount Schedule | 0DE2 |
| GTIN | 3606485413044 |
| Returnability | Yes |
| Country of origin | FR |
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Nbr. of units in pkg. | 1 |
| Package 1 Height | 0.591 in (1.500 cm) |
| Package 1 Width | 2.244 in (5.700 cm) |
| Package 1 Length | 2.480 in (6.300 cm) |
| Package weight(Lbs) | 2.131 oz (60.400 g) |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 120 |
| Package 2 Height | 11.811 in (30.000 cm) |
| Package 2 Width | 11.811 in (30.000 cm) |
| Package 2 Length | 15.748 in (40.000 cm) |
| Package 2 Weight | 16.861 lb(US) (7.648 kg) |
| Contractual warranty | |
| Warranty (in months) | 18 |
Product Datasheet
LV426841
LV426841
