Description
PLG100S - Appleton - 1" Square Head Steel Explosion Proof Close-Up Plug
Steel 1" conduit plug with slotted head for easy installation. Used to seal unused openings in boxes or fittings. Provides secure closure in general and industrial applications. Built for strength and reliability.
GENERAL SPECIFICATIONS
- NEC/CEC Certifications and Compliances
- Class I, Division 1 and 2, Groups A, B, C, D; Class II, Division 1 and 2, Groups E, F, G; Class III
- PLG Plugs Standard Materials and Finishes
- 1/2 thru 1: copperfree (4/10 of 1% max.) aluminum with natural finish or steel with zinc electroplate. 1-1/4 thru 6: copperfree (4/10 of 1% max.) aluminum with natural finish or malleable iron with zinc electroplate
- BR Reducers Standard Materials and Finishes
- Copperfree (4/10 of 1% max.) aluminum with epoxy powder coat finish or malleable iron triple-coat finish of (1) zinc electroplate, (2) chromate, and (3) epoxy powder coat
- Options
- Urethane paint available on select items (add suffix -UP)
PRODUCT DATASHEET
