NON-70 - Eaton Bussmann Series - Eaton Bussmann series NON fuse
| SKU | NON-70 |
| descriptionLabel | Eaton Bussmann Series Class H fuse, NON, general purpose, non-current-limiting fuses, 70 A, one-time fuse, interrupting rating of 10 kA at 250 Vac and 10 kA at 125 Vdc |
| Product Name | Eaton Bussmann series NON fuse |
| Catalog Number | NON-70 |
| UPC | 051712101653 |
| Product Length/Depth | 5.88 in |
| Product Height | 1.06 in |
| Product Width | 1.06 in |
| Product Weight | 0.3 lb |
| Warranty | Not Applicable |
| Compliances | CE Marked |
| Product Type | Fuse |
| Amperage Rating | 70 A |
| Interrupt rating | 50 kAIC at 125 Vdc 10 kAIC at 250 Vac |
| Voltage rating | 250 Vac, 125 Vdc |
| Packaging type | Standard |
| Class | Class H |
| Connection | Blade end x blade end |
| Fuse indicator | Non-indicating |
| Quantity | 5 |
| Special features | Non current limiting |
