PKOGTA7 - Schneider Electric - Square D Grounding Kit Safety Switch Equipment Grounding 800A
Schneider Electric's Square D heavy duty safety switch is designed to be tough, reliable and provide exceptional performance in the most grueling conditions. All heavy duty safety switches feature a quick-make, quick-break operating mechanism, a dual cover interlock, and a color coded indicator handle. They also come with many field installable or factory installed accessories. This equipment grounding kit is one of the available accessories. The grounding bar is rated for 800A and has 4 terminals which accept 4 AWG to 350kcmil conductor. The grounding kits are UL listed.
GENERAL SPECIFICATIONS
Main
| Range of Product |
Square D |
| Product or Component Type |
Safety switch grounding bar |
| Series name |
Heavy duty |
Complementary
| Line Rated Current |
800 A E2
800 A E4 |
| AWG gauge |
350 kcmil copper or aluminium |
| Tightening torque |
275 lbf.in (31.07 N.m) (AWG 4...350 kcmil) |
Ordering and shipping details
| Category |
US10DE100058 |
| Discount Schedule |
0DE1 |
| GTIN |
785901998402 |
| Returnability |
Yes |
| Country of origin |
MX |
Packing Units
| Unit Type of Package 1 |
PCE |
| Number of Units in Package 1 |
1 |
| Package 1 Height |
1.70 in (4.318 cm) |
| Package 1 Width |
6.80 in (17.272 cm) |
| Package 1 Length |
9.00 in (22.86 cm) |
| Package 1 Weight |
12.800 oz (362.874 g) |
