Description
QB1030EP - Eaton - 30A Single-Pole 120/240V QB GFCI Circuit Breaker Bolt-On Equipment Protection
Eaton QB GFCI circuit breaker,Bolt-on equipment protection,30A,10 kAIC,Single-pole,120/240V,Non-Interchangeable,30 mA Trip sensitivity,Bolt-on,#14-4 AWG,QB
GENERAL SPECIFICATIONS
| Product Name |
Eaton QB GFCI circuit breaker
|
| Catalog Number |
QB1030EP
|
| UPC |
786679186015
|
| Product Length/Depth |
4 in
|
| Product Height |
1 in
|
| Product Width |
3.5 in
|
| Product Weight |
0.4 lb
|
| Certifications |
UL 489
|
| Product Type |
GFCI circuit breakers
|
PHYSICAL ATTRIBUTES
| Circuit breaker type |
QB
|
| Connection |
Bolt-on
|
| Mounting Method |
Bolt-on
|
| Number of poles |
Single-pole
|
| Type |
Bolt-on equipment protection
|
| Wire size |
#14-4 AWG
|
PRODUCT SPECIFICATIONS
| Amperage Rating |
30 A
|
| Interrupt rating |
10 kAIC
|
| Trip Type |
Non-Interchangeable
|
| Trip rating |
30 mA trip sensitivity
|
| Voltage rating |
120/240 V
|
PRODUCT DATASHEET
