QBGFT2050 - Eaton Cutler Hammer - 50A 240V Quicklag GFCI Circuit Breakers
Eaton QB GFCI circuit breaker, Ground fault circuit breaker,50A,10 kAIC, Two-pole,120/240V,Common trip,5 mA Trip sensitivity,#8–6 Cu, #6–4 Al,QBGF
GENERAL SPECIFICATIONS
| Product Name |
Eaton QB GFCI circuit breaker
|
| Catalog Number |
QBGFT2050
|
| UPC |
786676026697
|
| Product Length/Depth |
6.5 in
|
| Product Height |
2 in
|
| Product Width |
3.5 in
|
| Product Weight |
0.8 lb
|
| Certifications |
UL 489
|
| Catalog Notes |
HACR rated
|
| Product Type |
GFCI circuit breakers
|
PHYSICAL ATTRIBUTES
| Circuit breaker type |
QBGF
|
| Mounting Method |
Bolt-on
|
| Number of poles |
Two-pole
|
| Type |
Ground fault circuit breaker
|
| Wire size |
#6–4 Al
#8–6 Cu |
PERFORMANCE RATINGS
| Amperage Rating |
50 A
|
| Interrupt rating |
10 kAIC
|
| Trip Type |
Common trip
|
| Trip rating |
5 mA trip sensitivity
|
| Voltage rating |
120/240 V
|
MISCELLANEOUS
| Special features |
5 mA Trip Sensitivity
|
