Description
GENERAL
| Application | Substation |
| Catalog Number | QGFL29B1 |
| Connector Type | Bus Bar Clamp and Accessories |
| Material | Copper Alloy |
| Material - Hardware | DURIUM™ Silicon Bronze |
| Plated | No |
| Plating Type | Unplated |
| Product Type | Mechanical |
| Sub Brand | BARTAP |
| Trade Name | BARTAP™ |
| Type | QGFL |
| UPC | 781810325124 |
| UPC 14 Digit GTIN | 00781810325124 |
DIMENSIONS
| Dimension - B Length fraction | 1-2/5 in |
| Dimension - B Length inch | 1.40 in |
| Dimension - Height fraction | 2-5/8 in |
| Dimension - Height inch | 2.63 in |
| Dimension - Height mm | 66.8 mm |
| Dimension - Width fraction | 1-3/8 in |
| Dimension - Width inch | 1.38 in |
| Dimension - Width mm | 35 mm |
| Package Height | 4.5 in |
| Package Length | 6.13 in |
| Package Weight | 6.12 lb |
| Package Width | 4.56 in |
CONDUCTOR RELATED
| Conductor - Copper Str Size | #6 Str;5 AWG;4 AWG;3 AWG;2 AWG;1 AWG;1/0 ;2/0 AWG;3/0 AWG;4/0 AWG;250 kcmil |
| Conductor - Copper Str Size Range | #6 Str-250 kcmil |
| Conductor Type | CU C Str-Size CU C Solid-Size |
CERTIFICATIONS AND COMPLIANCE
| Certification - CSA Approved | No |
| Certification - cULus | No |
| Certification - ETL | No |
| Certification - UL Listed Direct Burial | Yes |
| Certification - UL Recognized | No |
| Standards - RoHS Compliance Status | EX |
| UL Listed | No |
CONFIGURATION
| Connector Type | Bus Bar Clamp and Accessories |
LOGISTICS
| Carton Quantity | 12 |
| Minimum Pack Quantity | 1 |
| Pallet Quantity | 2400 |
