Description
QO1HT - Schneider Electric - Square D Handle Tie
QO and QOB Circuit Breakers have one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. They are designed to meet residential, commercial, and industrial requirements to protect electrical systems, equipment, and people. This circuit breaker accessory allows for adjecent single poles to be combined so that when one branch trips, equipment on the secondary circuits can be protected simultaneously. This products is certified to adhere to the specifications listed in the data sheet by UL. This product is a fixed attachment.
GENERAL SPECIFICATIONS
| Product Type | Handle tie |
| Marketing Trade Name | QO |
| Complementary | |
| Circuit Breaker Type | Standard |
| Ordering and shipping details | |
| Category | US1DE2E00108 |
| Discount Schedule | DE2E |
| GTIN | 785901518983 |
| Returnability | Yes |
| Country of origin | US |
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Nbr. of units in pkg. | 1 |
| Package 1 Height | 0.300 in (0.762 cm) |
| Package 1 Width | 3.500 in (8.890 cm) |
| Package 1 Length | 7.000 in (17.780 cm) |
| Package weight(Lbs) | 0.320 oz (9.072 g) |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 5 |
| Package 2 Height | 0.400 in (1.016 cm) |
| Package 2 Width | 3.500 in (8.890 cm) |
| Package 2 Length | 7.000 in (17.780 cm) |
| Package 2 Weight | 0.320 oz (9.072 g) |
| Unit Type of Package 3 | CAR |
| Number of Units in Package 3 | 100 |
| Package 3 Height | 4.100 in (10.414 cm) |
| Package 3 Width | 6.300 in (16.002 cm) |
| Package 3 Length | 7.100 in (18.034 cm) |
| Package 3 Weight | 9.120 oz (258.547 g) |
PRODUCT DATASHEET
Schneider Electric_Square-D-QO-and-QOB-Miniature-Circuit-Breakers_QO1HT
