Description
| Main | |
|---|---|
| Product Type | Lug kit |
| Marketing Trade Name | QO |
| Rated Current | 125 A |
| Number of Spaces | 3 |
| Number of Phases | 3 phase |
| Voltage Rating | 240 V AC |
| Complementary | |
| Number of Poles | 3 |
| Wire Size | 12 AWG...2/0 AWG copper or aluminium |
| Product Certifications | CSAcURus |
| Mounting Mode | Plug-in |
| Height | 3.500 in (88.900 mm) |
| Width | 2.241 in (56.921 mm) |
| Depth | 2.310 in (58.674 mm) |
| Environment | |
| Ambient Air Temperature for Operation | 23 °F (-5 °C)104 °F (40 °C) |
| Ordering and shipping details | |
| Category | US1DE2A00081 |
| Discount Schedule | DE2A |
| GTIN | 785901031338 |
| Returnability | Yes |
| Country of origin | MX |
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Nbr. of units in pkg. | 1 |
| Package 1 Height | 2.300 in (5.842 cm) |
| Package 1 Width | 3.400 in (8.636 cm) |
| Package 1 Length | 4.000 in (10.160 cm) |
| Package weight(Lbs) | 14.112 oz (400.068 g) |
| Contractual warranty | |
| Warranty (in months) | 18 |
Product Datasheet
QO3125SL
QO3125SL
