Description
| Main | |
|---|---|
| Product | Miniature circuit-breaker |
| Range | QO |
| Current Rating | 150 A |
| Voltage Rating | 240 V AC |
| Mounting Type | Bolt-on |
| Number of Poles | 3P |
| Circuit Breaker Type | Standard |
| Ratings | Not rated |
| Electrical Connection | Pressure plate |
| Complementary | |
| Interrupt Rating | 22 kA 240 V AC |
| Number of Panel Spaces | 6 |
| Wire Size | 4 AWG...300 kcmil copper or aluminium |
| Tightening Torque | 250.5 lbf.in (28.3 N.m) |
| Height | 5.7 in (145 mm) |
| Width | 4.5 in (114 mm) |
| Depth | 4.9 in (124 mm) |
| Product Weight | 0.549 lb(US) (0.249 kg) |
| Environment | |
| Certifications | UL ListedCSA |
| Ambient Rating | 104 °F (40 °C) |
| Ordering and shipping details | |
| Category | US10DE200015 |
| Discount Schedule | 0DE2 |
| GTIN | 785901065517 |
| Returnability | Yes |
| Country of origin | MX |
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Nbr. of units in pkg. | 1 |
| Package 1 Height | 4.300 in (10.922 cm) |
| Package 1 Width | 5.000 in (12.700 cm) |
| Package 1 Length | 6.700 in (17.018 cm) |
| Package weight(Lbs) | 3.979 lb(US) (1.805 kg) |
| Unit Type of Package 2 | PAL |
| Number of Units in Package 2 | 558 |
| Package 2 Height | 40.000 in (101.600 cm) |
| Package 2 Width | 40.000 in (101.600 cm) |
| Package 2 Length | 48.000 in (121.920 cm) |
| Package 2 Weight | 2199.0004 lb(US) (997.449 kg) |
| Contractual warranty | |
| Warranty (in months) | 18 |
Product Datasheet
QOB3150VH
