Description
| Main | |
|---|---|
| Range | PowerPact |
| Product name | PowerPact R |
| Product or Component Type | Circuit breaker |
| Device Application | Distribution |
| Complementary | |
| Line Rated Current | 2000 A |
| Number of Poles | 3P |
| Control Type | Operating handle |
| Breaking capacity code | G |
| Breaking capacity | AIR 65 kA 240 V AC 50/60 Hz UL 489AIR 35 kA 480 V AC 50/60 Hz UL 489AIR 18 kA 600 V AC 50/60 Hz UL 489Icu 50 kA 240 V AC 50/60 Hz IEC 60947-2Icu 35 kA 380/415 V AC 50/60 Hz IEC 60947-2 |
| [Ue] rated operational voltage | 600 V AC 50/60 Hz UL 489 |
| Network Frequency | 50/60 Hz |
| [Ics] rated service breaking capacity | 25 kA 240 V AC 50/60 Hz IEC 60947-220 kA 380/415 V AC 50/60 Hz IEC 60947-2 |
| [Uimp] rated impulse withstand voltage | 8 kV IEC 60947-2 |
| Trip unit technology | Electronic, ammeter, MicroLogic 3.0 A, LI |
| Continuous current rating | 80 % |
| [Ui] rated insulation voltage | 750 V IEC 60947-2 |
| Trip unit name | MicroLogic 3.0 A |
| Suitability for isolation | Yes IEC 60947-2 |
| Utilisation category | Category A |
| AWG gauge | 3/0 AWG...750 kcmil aluminium/copper |
| Local signalling | Alarm 1 LED yellow)long-time pick up) 1 LED red)long-time pick up)Trip causes 1 LED red) 1 LED red)digital ammeter)Phase-loading LED green)load balancing) |
| Mounting mode | Unit mount busbar) |
| Mounting Support | Busbar |
| Electrical connection | Busbar connection, lineBusbar connection, load |
| Terminal identifier | AL2500RK |
| Tightening torque | 601.8 lbf.in (68 N.m) 0.08…0.6 in² (50…400 mm²) (1/0 AWG...750 kcmil)601.8 lbf.in (68 N.m) 0.08…0.2 in² (50…150 mm²) (2 x 1/0 AWG...2 x 300 kcmil) |
| Number of slots | 2 auxiliary switch OF plug-in)1 alarm switch SD plug-in)1 voltage release MN or MX plug-in) |
| Power wire stripping length | 1.4 in (35 mm) |
| Height | 16.24 in (412.50 mm) |
| Width | 16.54 in (420.12 mm) |
| Depth | 14.49 in (368.05 mm) |
| Product Weight | 52 lb(US) (23.6 kg) |
| Quantity per Set | 1 |
| Circuit breaker application | HACR rated |
| Environment | |
| Quality labels | CE |
| Standards | ULCSANEMANMX J-266IEC 60947-2 |
| Product certifications | ULCSANOM |
| IP degree of protection | IP40 |
| Pollution degree | 3 IEC 60947-1 |
| Ambient Air Temperature for Operation | -13…158 °F (-25…70 °C) |
| Ambient Air Temperature for Storage | -58…185 °F (-50…85 °C) |
| Operating altitude | < 6561.68 ft (2000 m) without derating13123.36 ft (4000 m) with derating |
| Ordering and shipping details | |
| Category | US10DE201245 |
| Discount Schedule | 0DE2 |
| GTIN | 3606487116226 |
| Returnability | Yes |
| Country of origin | US |
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Nbr. of units in pkg. | 1 |
| Package 1 Height | 13.00 in (33.02 cm) |
| Package 1 Width | 20.0 in (50.8 cm) |
| Package 1 Length | 20.0 in (50.8 cm) |
| Package weight(Lbs) | 73.903 lb(US) (33.522 kg) |
| Contractual warranty | |
| Warranty (in months) | 18 |
