Description
Specifications
| Access Opening | Side |
| Configuration | T |
| Hub Location | Tee |
| Number of Hubs | 3 |
| Hub Size | 4 Inch |
| Size | 14.31 Inch Length x 6.94 Inch Width x 5.38 Inch Height |
| Installation | Threaded |
| Material | Zinc Electroplated/Chromate/Epoxy Powder Coated Grayloy-Iron (Body), Stainless Steel (Cover Screw) |
| Form Type | Form 7 |
| Approval | UL 514A/B, CSA C22.2 |
| Used On | IMC/Rigid Conduit |
| Brand Name | FM7™ |
| Additional Information | Wire Size (3) 3/0 AWG; Capacity 244 Cubic Inch; Enclosure Rating Class I Div 2; Application Commercial/Industrial, Hazardous/Wet Location; Applicable Standard NEC/CEC, NEMA FB-1 |
Product Datasheet
T107
T107
