Description
Specifications
| Access Opening | Side |
| Configuration | X |
| Hub Location | Cross |
| Number of Hubs | 4 |
| Hub Size | 2 Inch |
| Size | 5.25 Inch Width x 3.38 Inch Height |
| Installation | Threaded |
| Material | Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron (Body), Stainless Steel (Cover Screw) |
| Form Type | Form 35 |
| Approval | UL 514A/B, CSA C22.2 |
| Used On | IMC/Rigid Conduit |
| Brand Name | Form 35™ |
| Additional Information | Wire Size (3) 2/0 AWG; Capacity 71 Cubic Inch; Enclosure Rating Class I Div 2; Application Commercial/Industrial, Hazardous Location; Applicable Standard NEC/CEC, NEMA FB-1 |
