YH2929 - Burndy - Plate Copper
Roll over image to zoom in Click on image to zoom
YH2929 - Burndy - Plate Copper

YH2929 - Burndy - Plate Copper

BurndySKU: BURYH2929
Price:
$25.37
Stock:
50 In Stock and Ready To Ship

Description

Product Specifications

GENERAL

Application Wire Tap
Catalog Number YH2929
Color Code Purple
Connector Type H-TAP
Die Index 654
Finish Type Tin-Plated
Material Copper
Plated YES
Plating Type Tin
Product Family COMPRESSION
Product Type Run/Tap
Sub Brand CRIMPIT
Trade Name HYLUG™
Type Compression Taps
UPC 781810013830
UPC 14 Digit GTIN 00781810013830

DIMENSIONS

Dimension - Height inch 1.85 in
Dimension - L Length Overall mm 23 mm
Dimension - Length Overall inch 0.90 in
Dimension - Strip Length inch 1-1/16
Dimension - Width fraction .90 in
Dimension - Width inch 1.85 in
Package Height 0 in
Package Length 0 in
Package Weight 0 lb
Package Width 0 in

ELECTRICAL RATINGS

Voltage - Maximum 35000
Voltage Rating 35 kV

CONDUCTOR RELATED

Conductor - Copper Flex G Run 2 AWG;1 AWG;1/0 AWG;2/0 AWG;3/0 AWG;4/0 AWG
Conductor - Copper Flex G Run Range 2 AWG-4/0 AWG
Conductor - Copper Flex G Tap 2 AWG;1 AWG;1/0 AWG;2/0 AWG;3/0 AWG;4/0 AWG
Conductor - Copper Flex G Tap Range 2 AWG-4/0 AWG
Conductor - Copper Flex H Run 4/0 AWG
Conductor - Copper Flex H Run Range 4/0 AWG
Conductor - Copper Flex H Tap 2 AWG;1 AWG;1/0 AWG;2/0 AWG;3/0 AWG;4/0 AWG
Conductor - Copper Flex H Tap Range 2 AWG-4/0 AWG
Conductor - Copper Flex I Run 4/0 AWG-2 AWG
Conductor - Copper Flex I Run Range 2 AWG-4/0 AWG
Conductor - Copper Flex I Tap 2 AWG;1 AWG;1/0 AWG;2/0 AWG;3/0 AWG;4/0 AWG
Conductor - Copper Flex I Tap Range 4/0 AWG-2 AWG
Conductor - Copper Flex K Run 2 AWG;1 AWG;1/0 AWG;2/0 AWG;3/0 AWG;4/0 AWG
Conductor - Copper Flex K Run Range 2 AWG-4/0 AWG
Conductor - Copper Flex K Tap 2 AWG;1 AWG;1/0 AWG;2/0 AWG;3/0 AWG;4/0 AWG
Conductor - Copper Flex K Tap Range 2 AWG-4/0 AWG
Conductor - Copper Flex M Run 2 AWG;1 AWG;1/0 AWG;2/0 AWG;3/0 AWG;4/0 AWG
Conductor - Copper Flex M Run Range 2 AWG-4/0 AWG
Conductor - Copper Flex M Tap 2 AWG;1 AWG;1/0 AWG;2/0 AWG;3/0 AWG;4/0 AWG
Conductor - Copper Flex M Tap Range 2 AWG-4/0 AWG
Conductor - Copper Str Run 2 AWG;1 AWG;1/0 ;2/0 AWG;3/0 AWG;4/0 AWG;250 kcmil
Conductor - Copper Str Run Range 250 KCMIL-2 AWG
Conductor - Copper Str Tap 2 AWG;1 AWG;1/0 ;2/0 AWG;3/0 AWG;4/0 AWG;250 kcmil
Conductor - Copper Str Tap Range 250 KCMIL-2 AWG
Conductor - Material COPPER
Conductor Type CODE/FLEX

CERTIFICATIONS AND COMPLIANCE

Buy America(n) Qualified BABA Compliant (All status valid till December 2026)
Certification - CSA Approved Yes
Certification - cULus No
Certification - ETL No
Certification - UL Recognized No
Industry Standard(s) UL 486A-486B
Standards - Industry Standards Met UL467
Standards - RoHS Compliance Status CM
UL Listed Yes

CONFIGURATION

Connector Type H-TAP

LOGISTICS

Carton Quantity 50
Minimum Pack Quantity 1
Pallet Quantity 7200
Product Datasheet
YH2929
