Description
GENERAL
| Application | For Copper, Aluminum Or ACSR Conductors |
| Catalog Number | YP2U3 |
| Die Index | O |
| Material | Aluminum |
| Plated | No |
| Plating Type | Unplated |
| Prefilled Oxide Inhibitor | Y |
| Product Family | Utility Overhead & Underground Distribution>Compression Tap Connectors>C-Taps |
| Product Type | Compression |
| Sub Brand | CABELOK CRIMPIT |
| Trade Name | CABELOK™ CRIMPIT™ |
| Type | YP-U |
| UPC | 781810131732 |
| UPC 14 Digit GTIN | 00781810131732 |
DIMENSIONS
| Dimension - Height inch | 1.30 in |
| Dimension - L Length Overall mm | 38 mm |
| Dimension - Length Overall inch | 1.50 in |
| Dimension - Width inch | 0.72 in |
| Package Height | 0 in |
| Package Length | 0 in |
| Package Weight | 0 lb |
| Package Width | 0 in |
CONDUCTOR RELATED
| Conductor - ACSR Str Size A | 6 (6/1) Turkey AWG;5 (6/1) Thrush AWG;4 (6/1) Swan AWG;4 (7/1) Swanate AWG |
| Conductor - ACSR Str Size A Range | 6 (6/1) Turkey AWG-4 (7/1) Swanate AWG |
| Conductor - ACSR Str Size B | 6 (6/1) Turkey AWG;5 (6/1) Thrush AWG;4 (6/1) Swan AWG;4 (7/1) Swanate AWG |
| Conductor - ACSR Str Size B Range | 6 (6/1) Turkey AWG-4 (7/1) Swanate AWG |
| Conductor - AL Str Size A | 6 AWG;4 AWG |
| Conductor - AL Str Size A Range | 6 AWG-4 AWG |
| Conductor - AL Str Size B | 6 AWG;4 AWG |
| Conductor - AL Str Size B Range | 6 AWG-4 AWG |
| Conductor - Copper Solid Size A | 6 AWG;5 AWG;4 AWG;3 AWG;2 AWG |
| Conductor - Copper Solid Size A Range | 6 AWG-2 AWG |
| Conductor - Copper Solid Size B | 6 AWG;5 AWG;4 AWG;3 AWG;2 AWG |
| Conductor - Copper Solid Size B Range | 6 AWG-2 AWG |
| Conductor - Copper Str Size A | 6 AWG;5 AWG;4 AWG;3 AWG |
| Conductor - Copper Str Size A Range | 6 AWG-3 AWG |
| Conductor - Copper Str Size B | 6 AWG;5 AWG;4 AWG;3 AWG |
| Conductor - Copper Str Size B Range | 6 AWG-3 AWG |
CERTIFICATIONS AND COMPLIANCE
| Certification - CSA Approved | No |
| Certification - cULus | No |
| Certification - ETL | No |
| Certification - UL Recognized | No |
| Standards - RoHS Compliance Status | CM |
| UL Listed | No |
LOGISTICS
| Carton Quantity | 50 |
| Minimum Pack Quantity | 1 |
| Pallet Quantity | 3700 |
